Stock Motors

WEG Commercial Motors stocks a concentrated selection of motors covering a wide variety of todays most popular and demanding applications. Whether you’re looking for a motor for a Pump Application, Explosion Proof, Air Moving, Irrigation, or Washdown Duty, there’s a good chance that WEG Commercial Motors has the motor for you on our shelves. Weg Commercial Motors stock motors are made to the same exacting standards of quality and reliability that have become our trademark.

Available motor features

Electrical Specifications

• Single or Three Phase Design
• 2 & 4 pole motors (3450 or 1725 RPM)
• Standard 115/230 volt single phase or 230/460 volt three phase
• Continuous duty, continuous air over, or intermittent duty
• Horsepower range available 1/3 to 3hp
• Insulation system available: Class B, Class F, or Class F inverter duty
• Equipped with automatic or no thermal protection, depending upon the application
• Centrifugal mechanical starting switch
• Fixed rotation or reversible

Mechanical Specifications

• Face mounted NEMA C-face, J-Frame, or Thru-bolt mounts
• Rigid base, resilient base, or belly band mounting
• Open, Drip proof, TEFC, or TENV construction
• Permanently lubricated ball bearing construction systems
• Continuous duty, continuous air over or intermittent duty
• Shaft capabilities using standard carbon steel, stainless steel, or stress proof steel
• Standard 5/8″ shaft diameter with keyway on 56 frame motors (threaded shaft on J frame motors)
