48 & 56 Frame Motors

Nothing cuts into profits like poor product performance. It can lead to increased warranty claims, dealer frustration and—worst of all—dissatisfied customers. That’s why WEG Commercial Motors makes the toughest general purpose motors in the industry. Our motors offer you an incredible level of application flexibility yet never compromise on quality or reliability. The result is a family of general purpose motors being used by a variety of industries in virtually hundreds of applications.

Electrical Specifications

  • Single or Three Phase Design
  • Single speed or multi speed capability
  • 2, 4, 6, 8, 12 pole motors (3450, 1725, 1140, 850, 540)
  • Standard 115/230 volt single phase or 230/460 volt three phase
  • Continuous duty, continuous air over, or intermittent duty
  • Horsepower range available 1/6 to 5hp
  • 40°C, 50°C, or 60°C ambient
  • Insulation system available: Class B, Class F, or Class F inverter duty
  • Equipped with automatic, manual, or no thermal protection, depending upon the application
  • Centrifugal mechanical starting switch or Solid State Switch
  • Available in high starting torque, capacitor start designs, or normal starting torque three phase designs
  • Built to agency specifications by one or more of UL, CSA, NEMA, NEC and/or CE
  • Fixed rotation, reversible, or instantly reversible (using Bluffton’s patented Inst-O-Verse switch)

Mechanical Specifications

  • Face mounted NEMA C-face, square flange, or other custom flanges made of cast iron or aluminum
  • Rigid base, resilient base, or belly band mounting
  • Open, Drip proof, TEFC, or TENV construction
  • Permanently lubricated ball bearing construction systems
  • Shaft making capability using standard carbon steel, stainless steel, or stress proof steel, up to over an inch in diameter
  • Standard 5/8″ shaft diameter with keyway on 56 frame motors
  • Standard 1/2″ shaft diameter with flat on 48 frame motors
  • Custom shaft lengths with a maximum length of 22″
  • Connections can be made at a terminal board, conduit box, or leads or cords of various styles

WEG Commercial Motors supplies motors to original equipment manufacturers in the following markets

Commercial & Industrial Applications

  • Jet pumps
  • Metering pumps
  • Well pumps
  • High pressure sprayers
  • Hoists, cranes, & lifts

Medical, Dental, Lab Equipment

  • Lifts for hospital beds and dental chairs
  • Vacuum dental pumps

Pool & Spa Pumps

  • In ground swimming pool pumps
  • Spa & jetted tubs

Food Dispensing & Preparation

  • Slicers
  • Mixers
  • Ice cream dispensers
  • Dishwashers
  • Grinders

Petroleum & Chemical Industries

  • Gasoline dispensing pumps
  • General purpose explosion proof motors

Vacuum Pumps

  • Air compressors
  • Liquid ring
  • Sewage pumping & aeration


  • Sprayers
  • Mixers
  • Shakers

Irrigation & Agriculture

  • Center pivot irrigation drives
  • Fans for livestock ventilation
  • Poultry curtains

Special Requirements

Don’t see your application listed? No problem. We are confident we can produce a motor designed to your specifications. We can also test motors on your equipment in our engineering laboratories. Call us, and we’ll help you “turn” your next project reliably and profitably!

For special voltage, shafts or other design features, ‣ Contact your WEG Commercial Motor Account Manager
